Roll Crusher

Roll Crusher

The roller crusher has widely application in the industries of mining, building materials, chemical industry, metallurgy, etc. The roller crusher can crush materials with middle hardness or less than middle hardness into secondary or fine granularity, such as crushing mineral, rocks, coke, coal, slag, scoria, and fire-proof material etc.

Introduction:

The roller crusher has widely application in the industries of mining, building materials, chemical industry, metallurgy, etc. The roller crusher can crush materials with middle hardness or less than middle hardness into secondary or fine granularity, such as crushing mineral, rocks, coke, coal, slag, scoria, and fire-proof material etc.

roll crusher

Main applications:

Mainly used for the crushing of medium or lower-hardness mines and rocks with medium or lower rigidity in mine selection, chemicals, cement and building materials industrial production.

roll crusher

Working Principle:

The fixed part of roller and movable roller are driven by the motor via reducer and v-belt, the raw materials fall into the part between the two rollers from inlet of the machine. The two rollers rotates inward simultaneously. The materials are extruded, crushed and ground, then the end products come out from the bottom of this crusher.

Technical parameters

Model 2PG0425 2PG0640 2PG0740 2PG0850 2PG1060 2PG1260 2PG1560
Roller Diameter(mm) Ф400 Ф610 Ф700 Ф800 Ф1000 Ф1200 Ф1500
Roller Width(mm) 250 400 400 500 600 600 600
Feeding Size(mm) ≤25 ≤25 ≤25 ≤25 ≤30 ≤30 ≤30
Discharging Size(mm) 2-8 2-8 2-8 2-8 2-10 2-10 2-10
Capacity(t/h) 5-10 10-20 15-30 20-40 30-50 40-70 60-110
Motor Type Y132M-6 Y180L-6 Y200L-4 Y225M-4 Y250M-4 Y315M-6 Y315L-6
Motor Power(kw) 5.5-2 15*2 30*2 45*2 55*2 75*2 110*2
