Impact Crusher

Impact Crusher

Impact crusher which can also be called impact breaker is applicable for various hard and fragile materials such as limestone, coal, salt, gypsum, alum, brick and tile, etc in mining, transportation, energy, construction and chemical industry.

Brief Introduction to Impact Crusher

Impact crusher which can also be called impact breaker is applicable for various hard and fragile materials such as limestone, coal, salt, gypsum, alum, brick and tile, etc in mining, transportation, energy, construction and chemical industry. The crushing compressive strength of the materials should not be in excess of 150Mpa. Mobile impact crusher is mainly used in industries such as cement, coal separation, electricity generation, building materials and compound fertilizer, etc.

Impact Crusher

Major Features of Impact Crusher

1) High quality chrome hammer, abrasion resistance achieving the advanced level in our country

2) Specially designing tooth impact plate

3) Adjustable discharge open

4) High efficiency

5) Low power consumption unit

6) Favorable shape with aggregate and running smoothly

7) Big reduction ratio

8) Maximum feeding size is 1.3-1.5m; 3-150mm of discharging size

9) High fineness of discharging size

Unique Application of Impactor Breaker

As one of the mainly used crushing machines in the mining industry, impactor breaker plays a very important role and has wide application in many industrial departments. Like cone crusher, this series also has mobile types which is called mobile stone crusher machine. The mobile impact crusher is not only suitable for crushing rocks and ores, but for mineral resources, for this reason, it is also called mineral impact crusher.

Working Principle of Impact Crusher

When the imppact crushing machine works, the motor drives the rotor of the Impact stone crusher at high speed. When the materials get into the area which the hammers affect, under the impacting function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers work for being re-crushed. The materials from large to small are all to be crushed at the impact chamber repeatedly. The process won't stop till the material are crushed to the required size and then discharged from outlet of the impact crushing machine.

A Professional Impact Crusher Supplier in China-Hongxing Machinery

Henan Hongxing Mining Machinery Co., Ltd is a professional impact crusher supplier in China, and the China impact crusher is the best in quality and the most competitive in price. If you have any question with this impact crusher for sale, remember to pay a visit to our company.

Technical parameters

Model Specifications
(mm)
Feed opening
(mm)
Max.feeding side length
(mm)
Capacity
(t/h)
Power
(kw)
Total weight
(t)
Dimensions
( L×W×H)
(mm)
PF-1007 Φ1000×700 400×730 300 30-70 45 12 2330×1660×2300
PF-1010 Φ1000×1050 400×1080 350 50-90 55 15 2370×1700×2390
PF-1210 Φ1250×1050 400×1080 350 70-130 110 17.7 2680×2160×2800
PF-1214 Φ1250×1400 400×1430 350 100-180 132 22.4 2650×2460×2800
PF-1315 Φ1320×1500 860×1520 500 130-250 220 27 3180×2720×2620
PF-1520 Φ1500×2000 830×2040 700 300-550 400 50.6 3959×3564×3330

Note: Please feel free to give your inquiry in the form below. We will reply you in 24 hours.
