Magnetic Separator

Magnetic Separator

China Magnetic Separators are widely used to remove tramp iron from ores being crushed, to remove contaminating magnetic from food and industrial products, to recover magnetite and ferrosilicon in the float-sink methods of ore concentration, and to upgrade or concentrate ores.

Basic Information of Magnetic Separator

The magnetic separator can separate raw materials with different magnetic rigidities. The machine works under the magnetic force and machine force. Magnetic separators are designed to recover ferromagnetic materials. The main types of magnetic separator are dry type and wet type, and in addition, our company is also able to provide you with magnetic drum separator.

Magnetic Separator

Magnetic drum separator is the magnetic answer to heavy industrial applications such as tramp iron removal, slag treatment, ore cobbing and scrap fragmentizing. The Magnetic drum separator consists of an electromagnetic assembly mounted inside an outer rotating drum assembly. The magnet assembly position may be adjusted to meet varying feed and burden requirements. Its deeper magnetic field pattern, improved surface holding force and greater magnetic pole area achieves better separation than has previously been possible.

Separation Methods of Magnetic Separator

All materials possess magnetic properties. Substances that have a greater permeability than air are classified as paramagnetic; those with a lower permeability are called diamagnetic. Paramagnetic materials are attracted to a magnet; diamagnetic substances are repelled. Very strongly paramagnetic materials can be separated from weakly or nonmagnetic materials by the use of low-intensity magnetic separators. Minerals such as hematite, limonite, and garnet are weakly magnetic and can be separated from nonmagnetic by the use of high-intensity separators.

Technical parameters

Model Shell diameter
(mm)
Shell length
(mm)
Shell rotation speed
(r/min)
Feeding size
(mm)
Processing capacity
(t/h)
Power
(kw)
CTB6012 600 1200 <35 2-0 10-20 1.5
CTB6018 600 1800 <35 2-0 15-30 2.2
CTB7518 750 1800 <35 2-0 20-45 2.2
CTB9018 900 1800 <35 3-0 40-60 3
CTB9021 900 2100 <35 3-0 45-60 3
CTB9024 900 2400 <28 3-0 45-70 4
CTB1018 1050 1800 <20 3-0 50-75 5.5
CTB1021 1050 2100 <20 3-0 50-100 5.5
CTB1024 1050 2400 <20 3-0 60-120 5.5
CTB1218 1200 1800 <18 3-0 80-140 5.5
CTB1224 1200 2400 <18 3-0 85-180 7.5
CTB1230 1200 3000 <18 3-0 100-180 7.5
CTB1530 1500 3000 <14 3-0 170-280 11
