Concentrator Table

Concentrator Table

Table concentrator is a mine selecting machine for fine materials working by gravity. It is widely used in selection of Tin, tungsten, gold, silver, lead, zinc, tantalum, niobium, iron, manganese, ferrotitanium and coal.

The concentrator table is a selecting machine used in mining for fine materials working by gravity. It is widely used in selection of Tin, tungsten, gold, silver, lead, zinc, tantalum, niobium, iron, manganese, ferrotitanium and coal.

shaking table

Brief Introduction to Concentrator Table

The concentrator table is a selecting machine used in mining for fine materials working by gravity. It is widely used in selection of Tin, tungsten, gold, silver, lead, zinc, tantalum, niobium, iron, manganese, ferrotitanium and coal. Our company has long history of table concentrator production; we can provide a variety of table concentrators with high processing capacity, high recovery rate and high enrichment ratio.

The shaking concentrator unified the domestic shaking concentrator and the gravitational mineral separation technology; it has the merits of high enrichment ratio, good classification efficiency, simplicity of operator, and obtains the final ore concentrate and the final ore one time. Compared with the traditional process, it has the merits of little medicament, low energy consumption and convenient management. The concentrator table researched and developed by our company is extremely highly cost-effective. Concentrator table price is different according to various types.

Features of Concentrator Table

1. High enrichment ratio,

2. High separation precision,

3. High efficiency beneficiation,

4. High recovery ratio,

5. Easy installation and maintenance,

6. Simple operation,

7. The work safe and reliable,

8. Long working life,

9. It can eventually get the concentrates.

Operation Principle of Concentrator Table

Mineral separation by Shaking concentrator is Joint action of an inclined surface of bed with the aid of mechanical flagstone symmetrical reciprocal motion and thin layer incline current of water and so on, makes the ore grain on the surface of bed the loose lamination, thus enabling the mineral separation according to the different density.

Technical parameters of Concentrator table

Name Unit Grit concentrating table Fine sand concentrating table Sludge concentrating table
Dimensions Length Degree 4450 4450 4450
Driving part width Degree 1855 1855 1855
Concentrate part width Degree 1546 1546 1546
Max. feeding size Degree 2 0.5 0.15
Feeding amount T/d 30-60 10-20 15-25
Feeding thickness % 25-30 20-25 15-25
Journey Degree 16-22 11-16 8-16
Frequency F 15-48 48-53 50-57
Water quantity T/d 80-150 30-60 10-17
Horizontal obliquity 2.5-4.5 1.5-3.5 1-2
Portrait obliquity % 1.4 0.92 ----
Table board corner 32-42 40 42
Concentrating square ---- 7.6 7.6 7.6
Table board length ratio ---- 2.6 2.6 2.6
Motor power KW 1.1 1.1 1.1
